Jasmine Range
Hybrid Infrared Thermal Wave Panel (TWP)
Available in 300W, 500W, 700W, and 1000W models
Optional built-in digital thermostat or simple ON/OFF version
The Jasmine Range combines the advantages of infrared heating with natural air convection
for faster and more efficient warmth. Thanks to its hybrid technology, these panels can reduce energy
consumption by up to 15–30%, delivering both directional heat and warm air circulation.
The result is a quick, cost-effective heating solution ideal for modern spaces.
Why Choose the Thermal Wave Panel?
Thermal Wave Panels are suitable for both primary and supplemental heating. With a programmable thermostat,
users can fine-tune energy usage for maximum comfort and efficiency. These panels are maintenance-free,
environmentally friendly, and sized perfectly for discreet installation, such as under windows or along
low walls.
Features & Benefits
• Hybrid infrared + passive convection heating system
• Optional digital Built- in Thermostat
• Simple plug-and-play setup with 1.7-meter power cable and UK 3-pin plug
• Automatically maintains room temperature with energy-saving on/off cycling (With Built-in Thermostat)
• Supplied with all required mounting brackets and screws (Optional feet for a freestanding heater)
• Compact design ideal for residential or commercial use
• Surface temperature up to 90°C (Adjustable with the Built-in Thermostat)
• Certified by European Safety and TÜV standards
• Backed by a 5-year gold warranty
Installation Guidance
For optimal performance, avoid placing the panel directly facing windows or doors. Instead, orient the
heater into the room so walls, furniture, and floors can absorb and radiate the infrared warmth,
creating a consistent and comfortable indoor climate. A minimum 10cm gap from the edge of the panel to any furniture or walls is required. The Jasmine heater has a rating of IPXO, so it must be installed outside of any splash zones.
Model Specifications
| Model |
Power |
Dimensions |
Weight |
Voltage |
Heating Area |
TWP300WPremium (White & Thermostat)
TWP300BPremium (Black & Thermostat)
TWP300GPremium (White & Thermostat)
TWP300Basic (White & On/Off)
TWP300BBasic (Black & On/Off)
TWP300GBasic (Grey & On/Off) |
300W |
400 × 520 × 40mm |
2kg |
220–240V |
7m² |
TWP500WPremium (White & Thermostat)
TWP500BPremium (Black & Thermostat)
TWP500GPremium (Grey & Thermostat)
TWP500Basic (White & On/Off)
TWP500BBasic (Black & On/Off)
TWP500GBasic (Grey & On/Off) |
500W |
700 × 520 × 40mm |
4.7kg |
220–240V |
10m² |
TWP700WPremium (White & Thermostat)
TWP700BPremium (Black & Thermostat)
TWP700GPremium (Grey & Thermostat)
TWP700Basic (White & On/Off)
TWP700BBasic (Black & On/Off)
TWP700GBasic (Grey & On/Off) |
700W |
950 × 520 × 40mm |
6kg |
220–240V |
14m² |
TWP1000WPremium (White & Thermostat)
TWP1000BPremium (Black & Thermostat)
TWP1000GPremium (Grey & Thermostat)
TWP1000Basic (White & On/Off)
TWP1000BBasic (Black & On/Off)
TWP1000GBasic (Grey & On/Off) |
1000W |
1130 × 520 × 40mm |
7.4kg |
220–240V |
20m² |
